Rdt

Basic Info.

Model NO.	RDT-15B
Drive Type	Internal Combustion Drive
Bucket Capacity	0.1~0.5m³
Size	Small-Scale
Certification	CE, ISO9001: 2000
Condition	New
Max. Dumping Height	1750mm
Max. Digging Depth	1650mm
Max. Digging Height	2490mm
Boom Length	1480mm
Max. Digging Radius at Ground Level	2850mm
Min Swing Radius of Work Equipment	1470mm
Max. Digging Distance	3000mm
Max. Vertical Digging Depth	1400mm
Rotate Speed	13 R/Min
Travel Speed	1.5km/H
Engine Model	Koop/Yanmar
Fuel Tank	20L
Hydraulic Oil Tank	30L
Transport Package	Bare
Specification	2770*1000*2200
Origin	China
HS Code	8429521200
Production Capacity	300sets/Month

Product Description

Why choose B4YOU

1. We are a Chinese company specializing in construction machinery for more than 20 years;

2. A total of about 10,000 customers have selected B4YOU products;

3. We have our own R&D design team and large mechanical manufacturing factory ;

Choose B4YOU, an international trading partner that is more suitable for you.

Welcome partners to contact us to achieve business and provide customers with better B4YOU products.

11B Mini Excavator
Weight	1100kg	Engine	YANMAR / KUBOTA
Bucket capacity	0.03m3	Maximum digging height	2490mm
Machine size	2770x1000x2200mm	Maximum vertical digging depth	1650mm
Max earth digging diameter	2850mm	Rated power	10kw
Max uninstall height	1750mm	Max bulldozer digging height	325mm
Track width	180mm	Track length on land	1230mm

Company information
Packing and transport
FAQ

1: What certificates are available in machinery?

A: For the certificate, we have CE, ISO.

2: What about the delivery time?

A: 20 days after receiving the deposit.

3: What about the warranty?

A: We make 1 year warranty.

4. What about the Minimum Order Quantity?

A: The MOQ is 1 pcs .
